Embedded signal fault-detection laboratory

A completed embedded signal-processing study that detects hydraulic pump leakage from measured multirate sensor data under declared memory and compute limits.

Embedded signal fault-detection laboratory project visual
GP-EC-1PRZ799 · Electronics
  • Python
  • NumPy
  • SciPy
  • scikit-learn
  • Matplotlib
  • Jupyter

Project definition

Problem statement

Hydraulic pump leakage changes the relationship between pressure, electrical power, and flow signals, but other component conditions can create nuisance variation.

The engineering problem is to detect three leakage states from bounded signal windows while preventing related operating conditions from leaking between validation folds.

Project objectives

  • Prepare and verify the licensed UCI hydraulic condition-monitoring dataset.
  • Extract six streaming-compatible time features from each selected sensor.
  • Compare sensor suites and observation windows under grouped validation.
  • Emulate classifier and input quantisation at several bit widths.
  • Measure confidence rejection, sensor-loss sensitivity, model storage, working memory, and operation count.

Project structure

Project components

01

Dataset manager

Downloads, verifies, parses, and aligns the multirate hydraulic signals and condition labels.

02

Feature pipeline

Calculates mean, standard deviation, RMS, peak-to-peak, mean absolute delta, and delta standard deviation.

03

Grouped evaluator

Uses five-fold stratified group validation with fold-local scaling and training.

04

Quantisation study

Emulates classifier widths and ideal fixed-range ADC inputs without claiming physical hardware performance.

05

Deployment analysis

Calculates confidence coverage, sensor-loss effects, model bytes, working memory, and classifier operations.

Methodology

Project workflow

  1. 01
    Acquire

    Download the pinned UCI archive and confirm its SHA-256 digest.

  2. 02
    Prepare

    Align sensor cycles, select the stable primary subset, and retain nuisance-condition groups.

  3. 03
    Extract

    Build bounded feature vectors from declared sensors and observation windows.

  4. 04
    Evaluate

    Train and test every fold separately, then compare float and quantised predictions.

  5. 05
    Review

    Trace tables and figures to retained CSV and JSON results and state the failure boundaries.

Demonstration scenario

Run the retained study, compare the four-sensor 20-second candidate with the sensor and window sweeps, inspect its float and 8-bit confusion matrices, then remove each required sensor to show where the proposed deployment becomes unreliable.

Engineering

Tools and method

Tools
The project uses Python, NumPy, SciPy, scikit-learn, Matplotlib, Jupyter for subject analysis, simulation, and results.
Signal processing
NumPy and SciPy prepare multirate measurements and bounded time-domain features.
Classifier
A compact scikit-learn logistic regression model provides interpretable multiclass scores.
Validation
StratifiedGroupKFold separates cooler, valve, and accumulator condition combinations.
Embedded estimate
Quantised coefficients and fixed feature state provide explicit flash, RAM, and operation estimates.
Reproducibility
Pinned packages, deterministic folds, automated tests, retained outputs, and Docker support repeat the study.

Testing

Evaluation

Evaluation measures

  • 94.82 percent float accuracy and 94.81 percent balanced accuracy
  • 94.34 percent 8-bit classifier accuracy with 99.10 percent float agreement
  • 98.06 percent accepted accuracy at 88.75 percent coverage using a 0.65 confidence threshold
  • Five sensor suites, four observation windows, four classifier widths, and four ideal ADC resolutions compared
  • Estimated 276 bytes for model and scaling data, 316 bytes of feature state, and 72 classifier multiply-accumulates
  • Required sensor-loss tests expose accuracy reductions to between 53.49 and 85.02 percent

Project boundaries

  • The primary analysis excludes 756 cycles flagged as unstable by the source dataset.
  • The ADC study is an ideal fixed-range emulation and is not proof of physical converter adequacy.
  • Memory and operation values are analytical implementation estimates, not board measurements.
  • The project does not include hardware, firmware, a certified diagnostic device, or a safety-control function.
  • No information collected.

Included

  1. 01Measured 2,205-cycle hydraulic condition-monitoring dataset workflow
  2. 02Stable 1,449-cycle primary study with 48 nuisance-condition groups
  3. 03Streaming-compatible feature extraction for multirate sensor signals
  4. 04Sensor-suite, detection-window, classifier-width, and ideal ADC studies
  5. 05Five-fold grouped validation with float and 8-bit model results
  6. 06Confidence rejection, sensor-loss analysis, and embedded resource estimates
  7. 07Ten labelled project figures and three attributed literature images
  8. 08Twenty-nine automated tests with 97 percent branch coverage
  9. 09Complete source code, calculations, results, and analysis files in a private GitHub repository
  10. 10A 74-page project report in PDF and editable Word formats
  11. 11A 19-page setup and usage guide in PDF and editable Word formats
  12. 12Fifty annotated references
