GaN and SiC Power-Device Selection for High-Voltage EV Converters

A completed architecture-aware electronics study comparing GaN and SiC power-device evidence positions for 400 V and 800 V electric-vehicle converters.

GaN and SiC Power-Device Selection for High-Voltage EV Converters project visual
GP-EC-0H9T2WP · Electronics
  • Python 3.12
  • NumPy
  • pandas
  • Matplotlib

Project definition

Problem statement

GaN and SiC devices are often compared through isolated datasheet figures even though voltage class, topology, current, switching frequency, packaging, cooling, gate drive, EMI, qualification, and cost determine the converter result.

The engineering problem is to reject voltage-incompatible options first and then compare credible device-architecture pairs without presenting normalized datasheet positions as measured supplier rankings.

Project objectives

  • Define six traceable GaN and SiC device evidence positions.
  • Define seven 400 V and 800 V onboard charger, DC/DC, and traction architecture positions.
  • Calculate conduction, switching, reverse, gate-drive, electrothermal, density, and relative-cost indicators.
  • Compare case-temperature and switching-frequency sensitivity.
  • Quantify bounded uncertainty using 10,000 fixed-seed samples per compatible pair.
  • Build architecture-specific decision and Pareto shortlists with explicit engineering limits.

Project structure

Project components

01

Evidence positions

Retains voltage, resistance, charge, switching, reverse, thermal, qualification, maturity, and cost positions with source anchors.

02

Compatibility gate

Blocks device positions that cannot satisfy effective architecture voltage stress and derating.

03

Electrothermal model

Calculates parallel count, component loss, indicative efficiency, junction temperature, and eligibility across 270 cases.

04

Uncertainty model

Produces P05, median, and P95 loss, efficiency, and temperature positions with eligibility probability.

05

Decision analysis

Keeps efficiency, thermal margin, density, reliability, cost, driver complexity, and EMI evidence visible beside the final score.

06

Evidence package

Retains CSV, JSON, figures, tests, references, editable documentation, and a staged validation plan.

Methodology

Project workflow

  1. 01
    Declare

    Load the device and converter architecture evidence positions.

  2. 02
    Gate

    Reject voltage-incompatible device-architecture pairs before loss comparison.

  3. 03
    Calculate

    Evaluate loss and temperature at three case temperatures and three frequency factors.

  4. 04
    Test uncertainty

    Run 10,000 bounded samples for each compatible central pair.

  5. 05
    Rank

    Build architecture-specific scores and cost-loss Pareto sets from eligible cases.

  6. 06
    Review

    Trace every report value to retained results, equations, source annotations, and limitations.

Demonstration scenario

Run the study once, inspect the voltage-compatibility matrix, compare the central loss components, increase case temperature and frequency, then trace one architecture winner through uncertainty, decision score, and Pareto status. Explain why 650 V GaN is blocked from a two-level 800 V traction link but becomes eligible in a three-level position.

Engineering

Tools and method

Tools
The project uses Python 3.12, NumPy, pandas, Matplotlib for subject analysis, simulation, and results.
Device and architecture data
Python dictionaries define the traceable evidence and design positions.
Numerical analysis
NumPy and pandas implement deterministic, uncertainty, decision, and Pareto calculations.
Figures
Matplotlib generates twelve labeled comparison and sensitivity figures.
Documentation
The build creates editable Word and fixed PDF report and guide files with contents, figure, and table lists.
Reproducibility
A fixed seed, automated tests, repository checks, and Docker repeat the retained model.

Testing

Evaluation

Evaluation measures

  • Thirty voltage-compatible central device-architecture pairs
  • Two hundred seventy deterministic temperature and frequency cases
  • Conduction, switching, reverse-recovery, reverse-conduction, and gate loss separation
  • Estimated junction temperature and minimum thermal-margin eligibility
  • Ten-thousand-sample P05, median, and P95 uncertainty positions
  • Architecture-specific multi-criteria scores and twelve cost-loss Pareto cases
  • Seven automated tests and twelve reproducible figures

Project boundaries

  • All device values are normalized screening evidence positions, not supplier rankings or production design inputs.
  • Indicative efficiency excludes magnetic, capacitor, control, filter, and cooling-system losses.
  • Thermal, power-density, EMI, reliability, and cost values are screening positions and not measured compliance, lifetime, volume, or quotations.
  • The project contains no high-voltage hardware, safety case, functional-safety evidence, or certification.
  • Any hardware extension requires competent supervision, rated equipment, and an approved high-voltage laboratory.
  • No information collected.

Included

  1. 01Six normalized GaN and SiC device evidence positions
  2. 02Seven onboard charger, high-voltage DC/DC, and traction architecture positions
  3. 03Voltage compatibility before electrical comparison
  4. 04270 deterministic temperature and frequency cases
  5. 0510,000-sample uncertainty analysis for every compatible pair
  6. 06Architecture-specific decision scores and 12 Pareto cases
  7. 07Twelve generated result figures and one licensed literature figure
  8. 08Seven automated tests and clean-container reproduction
  9. 09Complete project files, calculations, results, and analysis in a private GitHub repository
  10. 1082-page project documentation in PDF and editable Word formats
  11. 1119-page setup and usage guide in PDF and editable Word formats
  12. 12Sixty annotated references with a complete source matrix
